Modul Breite Strom Strom@5V Beschreibung
A-119
8 30
A-120
8 30
A-121 12 30
A-122
8 20
8 20
A-123
A-124
8 30
A-125
8 20
A-126 8 80
A-127
28 100
A-127BOM
6 20
A-128
20 20
A-129-1 20 100
12 80
A-129-2
A-129-3 16 40
A-129-4 8 30
System A - 100
External Input / Envelope Follower
-
Input module for external audio signals, includes envelope follower and gate generator
24 dB Low Pass 1
-
voltage controlled 24 dB low pass (Moog type)
12 dB Multimode Filter
-
voltage controlled 12 dB multimode filter (low pass, high pass, band pass, notch)
24 dB Low Pass 2
-
voltage controlled 24 dB low pass (with CEM3320, Oberheim type)
24 dB High Pass
-
voltage controlled 24 dB high pass
VCF 5 - 12 dB Wasp Multimode Filter
-
reproduction of the strange multimode filter used in the EDP Wasp Synthesizer
VCP - Voltage Controlled Phaser
-
voltage controlled FET based phase shifter with resonance
VCFS - Voltage Controlled Frequency Shifter
-
voltage controlled analog frequency shifter
VCRF - Triple Voltage Controlled Resonance Filter
-
3 independent voltage controlled band pass filters with 3 LFOs
Breakout Module for A-127
-
separate access to each A-127 filter, 4 outputs and separate input for each filter
Fixed Filter Bank
-
filter bank with 15 band filters
Vocoder Analysis Section
-
Analysis section of the modular vocoder
Vocoder Synthesis Section
-
synthesis section of the modular vocoder
Vocoder Slew Limiter
-
universal 5-fold voltage controlled slew limiter/attenuator/offset generator
SLC - Slew Limiter Controller
-
controller module for slew limiter function of A-129/3
(module no longer available)
(combined manual A-105/A-122)
(module no longer available)
(module no longer available)
(module no longer available)
(module no longer available)
(module no longer available)
