DOEPFER SYSTEM A - 100 Bedienungsanleitung Seite 307

A-129 /1/2
Modularer Vocoder
2. A-129 /1, /2 - Übersicht
A-129 /1
VOCODER ANALYSIS SECTION
Speech
Input
Low Pass
High Pass
Out
2
System A - 100
VOC-A
Band 5
Band 1
Band 6
Band 2 Band 7
Band 3 Band 8
Band 4 Band 9
Control Voltage Outputs
Band 10
Band 11
Band 12
Band 13
High Pass
doepfer
A-129 /2
VOC-S
VOCODER SYNTHESIS SECTION
Instrument
Band 5
Low Pass
Input
Band 1
Band 6
Band 2 Band 7
Band 3 Band 8
Vocoder
Band 4 Band 9
Output
Control Voltage Inputs
Band 10
Band 11
Band 12
Band 13
High Pass
