9. Modulübersicht
Modul Breite Strom Strom@5V Beschreibung
A-143-2
26 70
A-143-3
14 70
A-143-4
22 100
A-143-9
8 30
A-144
8 30
A-145
8 30
A-146
8 20
A-147
8 40
A-148
4 20
A-149-1
12 40
A-149-2
4 40
A-150
4 30
A-151
4 20
A-152
16 40
32
System A - 100
Quad ADSR
-
Four ADSR envelope generators with EOA/EOD/EOR gate outputs and retrigger feature
Quad LFO
-
Four LFO modulation oscillators with triangle, rectangle and saw outputs, range switch
Quad VCLFO / VCO
-
Four VC oscillators with triangle and rectangle, range switch LFO/VCO, reset, direction
Quadrature LFO/VCO
-
voltage controlled LFO/VCO, four sine outputs with 90 degrees phase shift between e.a.
Morphing Controller
-
control voltage modifier to obtain morphing effects in combination with A-135
LFO 1
-
modulation oscillator with 5 waveforms
LFO 2
-
modulation oscillator with 2 waveforms and waveshape control
VCLFO
-
voltage controlled modulation oscillator with 4 waveforms
Dual S&H
-
two independent sample & hold devices
Quantized/Stored Random Voltages
-
Replica of the legendary Buchla module "Source of Uncertainty" (part 1)
Digital Random Voltages
-
expansion module for A-149-1, generates 8 digital random voltages/gates (high/low)
Dual VCS - Voltage Controlled Switsches
-
two independent voltage controlled switches
Quad Sequential Switch
-
electronical "rotary switch" with 4 positions
Voltage Addressed Switch
-
electronical 8-fold "rotary switch" with voltage controlled addressing
