Inverter-Parameter (Adresse / Auflösung /Typ)
Sub- CA
Index Type
Idx N
4800h 0 V UINT8
4801h 0 V UINT16
4802h 0 V UINT8
4810h 0 V UINT8
4811h 0 V UINT8
4812h 0 V UINT16
4813h 0 V UINT16
4817h 0 V UINT16
481Ah 0 V UINT8
481Bh 0 V UINT32
481Ch 0 V UINT8
481Dh 0 V UINT32
481Eh 0 V UINT8
481Fh 0 V UINT32
4820h 0 V UINT8
4821h 0 V UINT16
4823h 0 V UINT8
4824h 0 V UINT8
IDtxt Name
ec00 status encoder interface B
ec01 error encoder interface B
ec02 warning encoder interf. B
ec16 encoder type B
ec17 detected encoder type B
ec18 error encoder B
ec19 warning encoder B
ec23 system offset (SM) B
ec26 speed scan time B
ec27 speed PT1-time B
ec28 revolution range B
ec29 signal periods per revolution B
ec30 abs periods number B
ec31 zero pulse pos. B
ec32 max. pos. error B
ec33 abs. pos. accuracy B
ec35 pos. calc. mode B
ec36 set zero pos. B
Upper limit Lower limit Mult.
255 0
500 0
255 0
255 0
255 0
65535 0
65535 0
65535 0
7 0
256000 0
2 0
200000 0
10 1
200000 0
180 0
65535 0
7 0
1 0
nP
Div Unit RO
D
1 1 --- --- X
1 1 --- --- X
1 1 --- --- X
1 1 --- X ---
1 1 --- X X
1 1 --- --- X
1 1 --- --- X
1 1 --- --- ---
1 1 --- X ---
1 1000 ms X ---
1 1 --- X ---
1 1 --- X ---
1 1 --- X ---
1 1 INC X X
1 1 --- X ---
1 1 INC X ---
1 1 --- X ---
1 1 --- X X
