Factory settings
The display language is British English. It can be changed at
startup.
8.6.73 Units (4.5.2)
Units
Description
Here you can select units for the various parameters.
Select between SI and imperial units. You can also select other
units for the individual parameters.
Setting range
Basic setting
Parameter
SI Imperial
Pressure bar psi
Differential
m psi
pressure
Head m ft
Level m ft
3
Flow rate gpm
m /h
3
Volume gal
m
Specific
3
Wh/gal
kWh/m
energy
Temperature °C °F
Differential
K K
temperature
Power kW HP
Energy kWh kWh
If units are changed from SI to imperial or vice versa, all
individually set parameters will be changed to the basic
setting in question.
74
Possible units
kPa, MPa, mbar, bar, m, psi
kPa, MPa, mbar, bar, m, psi
m, cm, ft, in
m, cm, ft, in
3 3 3
m /s, m /h, l/s, gpm, yd /s,
3 3
yd /min, yd /h
3 3
l, m , gal, yd
3
kWh/m , Wh/gal, Wh/kgal,
BTU/gal, HPh/gal
K, °C, °F
K
W, kW, MW, HP
kWh, MWh, BTU, HPh
Setting via the operating panel
• Settings > Functions, CU 352 > Units.
Set unit standard, measuring parameter and specific unit. See the
example below.
Example of selection of units
Factory settings
The setting is done in the startup wizard and depends on the
application.
