8.3.7 Analog inputs (1.2.5)
Analog inputs
Description
The display shows an overview of the analog inputs and the
measured values of each input. See sections Analog inputs (4.3.8),
Analog inputs (4.3.8.1 - 4.3.8.7) and Analog inputs and measured
value (4.3.8.1.1 - 4.3.8.7.1).
Related information
8.6.30 Analog inputs (4.3.8)
8.6.31 Analog inputs (4.3.8.1 - 4.3.8.7)
8.6.32 Analog inputs and measured value (4.3.8.1.1 - 4.3.8.7.1)
8.3.8 Log graph (1.2.6)
Log graph
Description
The display shows logged data stored in the controller. Select log
values in the display Log values (4.4.9). Various values can be
shown, and the time scale can be changed.
Setting via the operating panel
Status > System > Log graph
1. Set as a percentage:
• Zoom begins at
• Zoom ends at.
2. Select values to be shown.
Related information
8.6.67 Log values (4.4.9)
8.3.9 Battery status (1.2.7)
Battery status
Description
The display shows the status of the backup battery, if installed.
