Pressure relief
Alarm, all pumps Stop
External fault
Stop
Dissimilar sensor
signals
Fault, primary
Stop
sensor
Fault, sensor
Communication
fault
Phase failure
Undervoltage,
pump
Overvoltage, pump
Overload, pump
Motor temperature
too high
Other fault, pump
Internal fault, CU
352
Internal fault, IO
Stop
351
VFD not ready
Fault, ethernet
Limit 1 exceeded
Limit 2 exceeded
Pressure buildup
fault
Pumps outside
duty range
Fault, pilot pump
Multisensor fault
Multisensor value
exceeds limits
Signal fault,
secondary sensor
Non-return valve
fault
Non-return valve
fault
28
Manual/
X 219
automatic
Automatic 203
Manual/
automatic
X 3
Manual/
automatic
Automatic 204
Automatic 89
Automatic 88
Automatic 10
Automatic 2
7, 40,
Automatic
42, 73
Automatic 32
48, 50,
Automatic
51, 54
64, 65,
Automatic
67, 70
Automatic 76, 83
83,
Automatic
157
72, 83,
Automatic
157
Automatic 213
231,
Automatic
232
Manual/
X 190
automatic
Manual/
X 191
automatic
Manual/
X 215
automatic
Manual/
X 208
automatic
Automatic 216
Automatic 143
Automatic X 87
Automatic X 93
Manual/
X 209
automatic
Manual/
X 209
automatic
8.5.2 Actual alarms (3.1)
Actual alarms
Description
The submenu in the display Alarm shows the following:
• Warnings caused by faults that still exist.
• Warnings caused by faults that have disappeared, but the
warning requires manual resetting.
• Alarms caused by faults that still exist.
• Alarms caused by faults that have disappeared, but the alarm
requires manual resetting.
All warnings and alarms with automatic resetting are automatically
removed from the menu when the fault has disappeared.
Alarms requiring manual resetting can be reset in this display
by pressing [OK]. An alarm cannot be reset until the fault has
disappeared.
For every warning or alarm, the following is shown:
• Whether it is a warning or an alarm
• Where the fault occurred: System, Pump 1, Pump 2, etc.
• In case of input-related faults, the input is shown.
• The cause of the fault and the alarm code in brackets, such as
"Water shortage (214)".
• When the fault occurred: Date and time.
• When the fault disappeared: Date and time. If the fault still
exists, date and time are shown as "--...--".
The most recent warning or alarm is shown at the top of the display.
Related information
8.5.3 Alarm log (3.2)
.
