Reading of rated power P (Grundfos Product Center)
nom
Pos. Description
Duty point, rated power P
1
Rated power P
2
nom
Q and H are the rated duty point of the pumps and
nom nom
usually the duty point with the highest efficiency.
Setting via the operating panel
• Settings > Secondary functions > Pump curve data.
• Select and set:
- Rated flow rate Qnom
- Rated head Hnom
- Max. head Hmax
- Max. flow rate Qmax
- Power, Q0, 100 % speed
- Power, Q0, 50 % speed
- Rated power Pnom.
Related information
8.3.10 Pump 1-6, Pilot pump (1.3 - 1.10)
58
1
2
nom
8.6.45 Control source (4.3.20)
Control source
Description
The system can be remote-controlled via an external bus
connection (option). See section GENIbus. For further information,
see section Data communication.
Select the control source, that is either CU 352 or the external bus
connection.
Setting via the operating panel
• Settings > Secondary functions > Control source.
Factory settings
The control source is CU 352.
Related information
8.7 Data communication
8.7.1 Ethernet
8.7.2 GENIbus
