X-Tack Packaged System
HeliX Tack Driver
Push Catheter
Push Catheter Release Button (Blue)
Handle Slider (Blue)
Cinch Packaged System
Plug & Collar
Suture Loading Tool
X-Tack Handle Function Overview
'Drive' (D) to implant HeliX Tack
'Reverse' (R) HeliX Tack or 'Reset'
the Handle after deployment
Push Catheter activated
Die Card
Handle
Die Card
Handle
Spacer
HeliX Tack Backer Card
Reload Pills (containing HeliX Tacks)
Scope Liner Funnel
Scope Liner Clamp (Red)
Bracket
Bracket Strap
Handle Slider
4
= Clockwise rotation (CW)
= Counter-clockwise rotation (CCW)
= Deployed HeliX Tack
