Aventics AV Systembeschreibung Seite 417

Tabell 30: Objektlista
Index Sub-Index
Name (referens)
hex hex
04 Write digital output
19h to 20h
... ... ...
320A Write digital output 8-bit
electric module 10
00 Highest subindex supported
01 Write digital output
01h to 08h
02 Write digital output
09h to 10h
03 Write digital output
11h to 18h
04 Write digital output
19h to 20h
3301 Read analogue input 16-bit
electric module 1
00 Highest sub-index supported
01 Read analogue input 01h
02 Read analogue input 02h
... ... ...
330A Read analogue input 16-bit
electric module 10
00 Highest subindex supported
01 Read analogue input 01h
02 Read analogue input 02h
3401 Write analogue output 16-bit
electric module 1
00 Highest subindex supported
01 Write analogue output 01h
02 Write analogue output 02h
... ... ...
340A Write analogue output 16-bit
electric module 10
00 Highest subindex supported
01 Write analogue output 01h
02 Write analogue output 02h
3501 Channel diagnostic electric
module 1
00 Highest subindex supported
01 Chdiag 01h to 08h
02 Chdiag 09h to 10h
03 Chdiag 11h to 18h
04 Chdiag 19h to 20h
... ... ...
AVENTICS | Fältbussnod AES/Ventildrivenhet AV CANopen | R412018137–BAL–001–AE
Attribut Mapbar Objekttyp
rw j
... ... ...
ARRAY
ro n
rw j
rw j
rw j
rw j
ARRAY
ro n
ro j
ro j
... ... ...
ARRAY
ro n
ro j
ro j
ARRAY
ro n
rw j
rw j
... ... ...
ARRAY
ro n
rw j
rw j
ARRAY
ro n
ro j
ro j
ro j
ro j
... ... ...
Default-Wert,
Datatyp
giltighetsområde (1)
UNSIGNED8 00h
... ...
UNSIGNED8 Antal elektriska digitala
8-bit outputs, modul 10
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 Antal elektriska analoga
16-bit inputs, modul 1
INTEGER16 no
INTEGER16 no
... ...
UNSIGNED8 Antal elektriska analoga
16-bit inputs, modul 10
INTEGER16 no
INTEGER16 no
UNSIGNED8 Antal elektriska analoga
16-bit outputs, modul 1
INTEGER16 00h
INTEGER16 00h
... ...
UNSIGNED8 Antal elektriska analoga
16-bit outputs, modul 10
INTEGER16 00h
INTEGER16 00h
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
... ...
417
Bilaga
