Tabella 30: Dizionario degli Oggetti
Index in Sub-Index
Nome (riferimento)
Hex in Hex
00 Highest subindex supported
01 Write analogue output 01h
02 Write analogue output 02h
2501 Channel diagnostic
pneumatic module 1
00 Highest subindex supported
01 Chdiag 01h to 08h
02 Chdiag 09h to 10h
03 Chdiag 11h to 18h
04 Chdiag 19h to 20h
... ... ...
2520 Channel diagnostic
pneumatic module 32
00 Highest subindex supported
01 Chdiag 01h to 08h
02 Chdiag 09h to 10h
03 Chdiag 11h to 18h
04 Chdiag 19h to 20h
2601 00 Parameter pneumatic
module 1
... ... ...
2620 00 Parameter pneumatic
module 32
2701 00 Info pneumatic module 1
... ... ...
2720 00 Info pneumatic module 32
3101 Read digital input 8-bit
electric module 1
00 Highest sub-index supported ro
01 Read digital input
01h to 08h
02 Read digital input
09h to 10h
03 Read digital input
11h to 18h
04 Read digital input
19h to 20h
... ... ...
310A Read digital input 8-bit
electric module 10
00 Highest subindex supported
01 Read digital input
01h to 08h
02 Read digital input
09h to 10h
AVENTICS | Accoppiatore bus AES/driver valvole AV, CANopen | R412018137–BAL–001–AE
Attributo mappabile Tipo di oggetto Tipo dati
ro N
rw j
rw j
ARRAY
ro N
ro j
ro j
ro j
ro j
... ... ...
ARRAY
ro N
ro j
ro j
ro j
ro j
rw N VAR
... ... ...
rw N VAR
ro N VAR
... ... ...
ro N VAR
ARRAY
N
ro j
ro j
ro j
ro j
... ... ...
ARRAY
ro N
ro j
ro j
Valore di default,
campo di validità (1)
UNSIGNED8 Numero di output analogici
pneumatici da 16 bit,
modulo 32
INTEGER16 00h
INTEGER16 00h
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
... ...
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
UNSIGNED8 00h
DOMAIN
... ...
DOMAIN
DOMAIN
... ...
DOMAIN
UNSIGNED8 Numero di input digitali
elettrici da 8 bit, modulo 1
UNSIGNED8 no
UNSIGNED8 no
UNSIGNED8 no
UNSIGNED8 no
... ...
UNSIGNED8 Numero di input digitali
elettrici da 8 bit, modulo 10
UNSIGNED8 no
UNSIGNED8 no
275
Appendice
