Aventics AV Systembeschreibung Seite 414

414 AVENTICS | Fältbussnod AES/Ventildrivenhet AV CANopen | R412018137–BAL–001–AE
Bilaga
Tabell 30: Objektlista
Index Sub-Index
Name (referens)
hex hex
01 Status pneumatic
modules 1 to 32
02 Enable pneumatic
modules 1 to 32
03 Status electric modules 1 to
10 and Bus module 0
04 Enable electric modules 1 to
10 and Bus module 0
2012 Voltage diagnostic
01 Voltage diagnostic status
02 Voltage diagnostic enable
2013 SLS diagnostic
01 Error counter since restart
02 Error counter current
03 Number of IO modules
04 Number of pneumatic
modules
2101 Read digital input 8-bit
pneumatic module 1
00 Highest sub-index supported
01 Read digital input
01h to 08h
02 Read digital input
09h to 10h
03 Read digital input
11h to 18h
04 Read digital input
19h to 20h
... ... ...
2120 Read digital input 8-bit
pneumatic module 32
00 Highest subindex supported
01 Read digital input 01h to 08h
02 Read digital input 09h to 10h
03 Read digital input
11h to 18h
04 Read digital input
19h to 20h
2201 Write digital output 8-bit
pneumatic module 1
00 Highest subindex supported
01 Write digital output
01h to 08h
02 Write digital output
09h to 10h
03 Write digital output
11h to 18h
Attribut Mapbar Objekttyp
ro j
rw j
ro j
rw j
ARRAY
ro j
rw j
RECORD
ro n
ro n
ro n
ro n
ARRAY
ro n
ro j
ro j
ro j
ro j
... ... ...
ARRAY
ro n
ro j
ro j
ro j
ro j
ARRAY
ro n
rw j
rw j
rw j
Datatyp
UNSIGNED32
UNSIGNED32
UNSIGNED32
UNSIGNED32
UNSIGNED16
UNSIGNED16
UNSIGNED32
UNSIGNED32
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
...
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
Default-Wert,
giltighetsområde (1)
0000 0000h
FFFF FFFFh
0000 0000h
8000 03FFh
0000h
FFFFh
no
no
no
no
Anta digitala pneumatiska
8-bit-inputs, modul 1
no
no
no
no
...
Antal pneumatiska digitala
8-bit inputs, modul 32
no
no
no
no
Antal digitala pneumatiska
8-bit outputs, modul 1
00h
00h
00h
