AVENTICS | Bus Coupler AES/Valve Driver AV, CANopen | R412018137–BAL–001–AE
12.2.6

Pressure regulators

You can use electronically operated pressure regulators as a pressure zone control or single
pressure control depending on the selected base plate.
39
41
42
Fig. 14: Base plate for pressure regulators for pressure zone control (left) and single pressure control (right)
39 AV-EP base plate for pressure zone control
40 AV-EP base plate for single pressure control
Pressure regulators for pressure zone control and single pressure control do not differ in terms
of electronic control. This is why the differences between the two AV-EP pressure regulators are
not discussed in further detail here. The pneumatic functions are described in the operating
instructions for AV-EP pressure regulators, which can be found on CD R 412018133.
Conversion of the Valve System
40
41
42
A
41 Integrated AV-EP circuit board
42 Valve position for pressure regulator
111
