416 AVENTICS | Fältbussnod AES/Ventildrivenhet AV CANopen | R412018137–BAL–001–AE
Bilaga
Tabell 30: Objektlista
Index Sub-Index
Name (referens)
hex hex
2520 Channel diagnostic pneumatic
module 32
00 Highest subindex supported
01 Chdiag 01h to 08h
02 Chdiag 09h to 10h
03 Chdiag 11h to 18h
04 Chdiag 19h to 20h
2601 00 Parameter pneumatic module
1
... ... ...
2620 00 Parameter pneumatic module
32
2701 00 Info pneumatic module 1
... ... ...
2720 00 Info pneumatic module 32
3101 Read digital input 8-bit
electric module 1
00 Highest sub-index supported
01 Read digital input
01h to 08h
02 Read digital input
09h to 10h
03 Read digital input
11h to 18h
04 Read digital input
19h to 20h
... ... ...
310A Read digital input 8-bit
electric module 10
00 Highest subindex supported
01 Read digital input
01h to 08h
02 Read digital input
09h to 10h
03 Read digital input
11h to 18h
04 Read digital input
19h to 20h
3201 Write digital output 8-bit
electric module 1
00 Highest subindex supported
01 Write digital output
01h to 08h
02 Write digital output
09h to 10h
03 Write digital output
11h to 18h
Attribut Mapbar Objekttyp
ARRAY
ro n
ro j
ro j
ro j
ro j
rw n VAR
... ... ...
rw n VAR
ro n VAR
... ... ...
ro n VAR
ARRAY
ro n
ro j
ro j
ro j
ro j
... ... ...
ARRAY
ro n
ro j
ro j
ro j
ro j
ARRAY
ro n
rw j
rw j
rw j
Datatyp
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
DOMAIN
...
DOMAIN
DOMAIN
...
DOMAIN
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
...
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
UNSIGNED8
Default-Wert,
giltighetsområde (1)
00h
00h
00h
00h
00h
...
...
Antal digitala elektriska
8-bit inputs, modul 1
no
no
no
no
...
Antal elektriska digitala
8-bit inputs, modul 10
no
no
no
no
Antal elektriska digitala
8-bit outputs, modul 1
00h
00h
00h
