P P o o w w e e r r - - L L O O A A D D assembly kit components (6390-001-054)
(1) Socket head cap screw (0004-
658-000)
(4) Anchor mounting post (6390-001-
150)
(1) Transfer trim, head end, left
(639000010210)
(2) Dead stop block, threaded
(639000010246)
(4) Floor plate attachment bracket
(6390-101-108)
(1) Anchor inductive primary cover
(639001010101)
A A d d d d i i t t i i o o n n a a l l p p a a r r t t s s u u s s e e d d ( ( n n o o t t i i n n c c l l u u d d e e d d ) )
Electrical tape
T T o o o o l l s s r r e e q q u u i i r r e e d d : :
5/32'' hex wrench
Flat blade screwdriver
T25 Torx driver
P P r r o o c c e e d d u u r r e e : :
1. Lift the vehicle bumper to the raised position, if equipped.
2. Using a measuring tape, measure from the end of the floor plate to the end of the bumper to determine how far you can
move the anchor toward the head end (Figure 3).
N N o o t t e e - - If the distance measured is less than 18 in. (46 cm), you can shift P P o o w w e e r r - - L L O O A A D D closer to the head end of the
vehicle patient compartment by a maximum of 18 in. (46 cm) and the measured distance.
W W A A R R N N I I N N G G - - Always allow for bumper clearance. Inadequate bumper clearance could result in patient or operator
injury.
6390-809-005 Rev AA.0
(4) Socket head cap screw (0004-662-
000)
(1) Trolley magnet activator (6390-001-
106)
(2) Dead stop bumper (639000010243) (1) Transfer wear pad, foot end (6390-
(2) Dead stop block, thru hole
(639000010244)
(4) Sub anchor attachment bracket
(6390-001-110)
Measuring tape
3/8'' hex wrench
1/2'' drive torque wrench (ft-lb) > 60 ft-
lb
F F i i g g u u r r e e 3 3 – – M M e e a a s s u u r r e e f f o o r r a a n n c c h h o o r r i i n n s s t t a a l l l l a a t t i i o o n n
(6) Button head cap screw (0004-665-
000)
(1) Transfer trim, head end, right
(639000010211)
001-225)
(4) Flat head cap screw (0001-194-
000)
(2) Floor plate cover, short (6390-001-
166)
Saw
3/16'' hex wrench
Rubber hammer
