I I n n s s t t a a l l l l a a t t i i o o n n v v e e r r i i f f i i c c a a t t i i o o n n
Complete these checks to verify your P P o o w w e e r r - - L L O O A A D D installation follows Stryker recommended best practices.
F F o o r r f f l l o o o o r r p p l l a a t t e e i i n n s s t t a a l l l l a a t t i i o o n n : :
Confirm that the floor plate was installed according to the Stryker Global Floor Plate Installation Manual (6390-009-
020).
Make sure that all floor plate tie-down bolts are set to a minimum torque of 40 ft-lb (54.3N-m) in at least a two-step
tightening process.
Visually check that the floor plate sits flat on the floor deck.
Confirm that the vehicle circuit can continuously deliver 12.8V-15.6V DC under a maximum load of 10A.
W W A A R R N N I I N N G G - - A A l l w w a a y y s s c c o o n n n n e e c c t t P P o o w w e e r r - - L L O O A A D D t t o o a a 1 1 5 5 A A f f u u s s e e / / r r e e s s e e t t t t a a b b l l e e b b r r e e a a k k e e r r t t h h a a t t i i s s i i n n s s t t a a l l l l e e d d i i n n t t h h e e v v e e h h i i c c l l e e t t o o
p p r r e e v v e e n n t t e e l l e e c c t t r r i i c c a a l l h h a a z z a a r r d d s s . . S S t t r r y y k k e e r r r r e e c c o o m m m m e e n n d d s s t t h h a a t t y y o o u u i i n n s s t t a a l l l l t t h h e e f f u u s s e e / / r r e e s s e e t t t t a a b b l l e e b b r r e e a a k k e e r r i i n n t t h h e e f f u u s s e e b b o o x x . .
Make sure that the product is wired to the vehicle battery bank (Stryker's preferred installation method).
W W A A R R N N I I N N G G - - D D o o n n o o t t c c o o n n n n e e c c t t P P o o w w e e r r - - L L O O A A D D t t o o a a 2 2 4 4 V V D D C C v v e e h h i i c c l l e e c c i i r r c c u u i i t t . .
Make sure that the installed floor plate bolts are 3/8-16 UNC flat head cap screws (ASTM-F835 or SAE grade 8).
N N o o t t e e - - Each floor plate bolt and support structure must be able to withstand 2,750 lbf (12,230 N) in upward tension
and 600 lbf (2,669 N) in shear in all horizontal directions.
You can cut the floor plate, if necessary (minimum 89.50 in. (227.33 cm) for P P o o w w e e r r - - L L O O A A D D ). Only remove material from the
head end.
F F o o r r f f l l o o o o r r p p l l a a t t e e a a n n d d P P o o w w e e r r - - L L O O A A D D i i n n s s t t a a l l l l a a t t i i o o n n : :
Complete the floor plate installation checks above.
Confirm Installing Power-LOAD (page 14).
Confirm Installing the battery (page 24).
Confirm completion of the Installation checklist (page 25).
Load and unload the P P o o w w e e r r - - L L O O A A D D compatible cot with power to check for functionality ( Loading and unloading with
powered operations (page 34)).
Load and unload the P P o o w w e e r r - - L L O O A A D D compatible cot without power to check for functionality ( Loading and unloading
with manual operations (page 35)).
Make sure that the battery power LED is flashing green when the trolley is in the transport position.
Make sure that the anchor seals are installed into the grooves of the anchor assembly.
Visually inspect the head end transfer bumpers to make sure that they are installed flush to the outer edge of the
transfer assembly with no signs of misalignment or improper installation.
Visually check that all bolts and screws are tight, with no signs of protruding or missing fasteners.
If the trolley LEDs stay off when the trolley reaches the loading position, confirm that the trolley is powered on and
the battery is charged. Also make sure that the magnet activator (6390-001-106) is present and that it is fastened at
the foot end of the anchor.
Confirm that the torque for the supplied anchor mounting posts is 60 ±10 ft-lb.
If you will not use P P o o w w e e r r - - L L O O A A D D for a week or more, press the main power button to turn the product off and avoid
draining the battery.
Turn the product on and then off to make sure that P P o o w w e e r r - - L L O O A A D D is off and not in sleep mode.
Stryker offers a wheel guide option if you install the P P o o w w e e r r L L O O A A D D system close to the wall. See Installing the optional
wheel guide (6390-009-021).
Call Stryker service at 1-800-327-0770 if you need help after installation.
6390-809-005 Rev AA.0
27
EN
