R&S Scope Rider RTH
Parameter:
<ThresholdValue>
LOGic:GROup<m>:THReshold?
Returns the current threshold value.
Suffix:
<m>
Rückgabewerte:
<Level>
Verwendung:
LOGic:GROup<m>:HYSTeresis <Hysteresis>
Hysteresis avoids the change of signal states due to noise oscillation around the thres-
hold level. Set a small hysteresis for clean signals, and large hysteresis for noisy sig-
nals.
Suffix:
<m>
Parameter:
<Hysteresis>
LOGic:CHANnel<m>:DESKew <Value>
Sets the deskew for all channels of a logic probe at once, or for each logic channel
separately.
Suffix:
<m>
Benutzerhandbuch 1326.1578.03 ─ 19
Bereich: -400 bis 400
Inkrement: 1E-3
*RST: 1.4
Std.-einheit: V
.
1..3
1 = all logic channels D0 to D7
2 = group D0 to D3
3= group D4 to D7
Bereich: -10 bis 10
Inkrement: 1E-3
*RST: 0
Std.-einheit: V
Nur Abfrage
.
1..3
1 = all logic channels D0 to D7
2 = group D0 to D3
3= group D4 to D7
The suffix only takes effect if
SMALl | MEDium | LARGe
*RST: MEDium
.
1..9
1..8: logic channels 0 to 7
9: all logic channels
Fernsteuerbefehle
Logikanalysator (R&S RTH-B1 MSO)
LOGic:THCoupling
is OFF.
