R&S Scope Rider RTH
<sb:DATA-SIZE>20</sb:DATA-SIZE>
<sb:SIGNALS>
<sb:SIGNAL ID="Channel_1">
</sb:SIGNAL>
<sb:SIGNAL ID="Channel_2">
</sb:SIGNAL>
</sb:SIGNALS>
</sb:FRAME>
<sb:FRAME NAME="Dual Throttle Position" STATE="OFF">
<sb:SHORT-NAME>DTP</sb:SHORT-NAME>
<sb:DATA-SIZE>24</sb:DATA-SIZE>
<sb:SIGNALS>
<sb:SIGNAL ID="Channel_1">
</sb:SIGNAL>
<sb:SIGNAL ID="Channel_2">
Benutzerhandbuch 1326.1578.03 ─ 19
<sb:SHORT-NAME>TPS1</sb:SHORT-NAME>
<sb:DESCRIPTION>""</sb:DESCRIPTION>
<sb:BIT-POSITION>19</sb:BIT-POSITION>
<sb:BIT-LENGTH>12</sb:BIT-LENGTH>
<sb:BYTE-ORDER>MSB</sb:BYTE-ORDER>
<sb:VALUE-TYPE>UNSIGNED_INT</sb:VALUE-TYPE>
<sb:FACTOR>1.0</sb:FACTOR>
<sb:OFFSET>0.0</sb:OFFSET>
<sb:MIN>0</sb:MIN>
<sb:MAX>10000.0</sb:MAX>
<sb:UNIT></sb:UNIT>
<sb:SHORT-NAME>TPS2</sb:SHORT-NAME>
<sb:DESCRIPTION>""</sb:DESCRIPTION>
<sb:BIT-POSITION>7</sb:BIT-POSITION>
<sb:BIT-LENGTH>8</sb:BIT-LENGTH>
<sb:BYTE-ORDER>LSB</sb:BYTE-ORDER>
<sb:FACTOR>1.0</sb:FACTOR>
<sb:OFFSET>0.0</sb:OFFSET>
<sb:MIN>0</sb:MIN>
<sb:MAX>10000.0</sb:MAX>
<sb:UNIT></sb:UNIT>
<sb:SHORT-NAME>TPS1</sb:SHORT-NAME>
<sb:DESCRIPTION>""</sb:DESCRIPTION>
<sb:BIT-POSITION>23</sb:BIT-POSITION>
<sb:BIT-LENGTH>12</sb:BIT-LENGTH>
<sb:BYTE-ORDER>MSB</sb:BYTE-ORDER>
<sb:VALUE-TYPE>UNSIGNED_INT</sb:VALUE-TYPE>
<sb:FACTOR>1.0</sb:FACTOR>
<sb:OFFSET>0.0</sb:OFFSET>
<sb:MIN>0</sb:MIN>
<sb:MAX>10000.0</sb:MAX>
<sb:UNIT></sb:UNIT>
<sb:SHORT-NAME>TPS2</sb:SHORT-NAME>
<sb:DESCRIPTION>""</sb:DESCRIPTION>
<sb:BIT-POSITION>11</sb:BIT-POSITION>
