R&S Scope Rider RTH
ACQuire:POINts:ARATe?
Returns the number of captured analog waveform points per second (sample rate of
the ADC).
Rückgabewerte:
<ADCSampleRate>
Verwendung:
ACQuire:POINts[:VALue]?
Returns the record length, number of captured waveform samples before interpolation.
Rückgabewerte:
<RecordLength>
Verwendung:
ACQuire:RESolution?
Returns the resolution, the time between two waveform samples.
Rückgabewerte:
<ResolutionPP>
Verwendung:
15.3.5 Trigger
● Allgemeine
● Flankentrigger....................................................................................................... 335
● Glitch-Trigger........................................................................................................ 335
● Pulsbreitentrigger.................................................................................................. 336
● Video/TV-Trigger................................................................................................... 338
● Externer Trigger (R&S
● Mustertrigger (R&S
● Zustandstrigger (R&S
● Runt-Trigger (R&S
● Anstiegszeitentrigger (R&S
● Data2Clock-Trigger (R&S
● Trigger für serielle Muster (R&S
Benutzerhandbuch 1326.1578.03 ─ 19
1 active channel: 5 Gsample/s
2 active channels: 2.5 Gsample/s
3 or 4 active channels: 1.25 Gsample/s
Std.-einheit: Sa/s
Nur Abfrage
Bereich: 1 bis 4294967295
Inkrement: 1
*RST: 1
Std.-einheit: Sa
Nur Abfrage
Bereich: 1E-12 bis 1E+12
Inkrement: 1E-12
*RST: 0
Std.-einheit: s
Nur Abfrage
Triggereinstellungen...........................................................................332
RTH1002)......................................................................... 340
RTH-K19).............................................................................. 341
RTH-K19).......................................................................... 344
RTH-K19)............................................................................... 345
RTH-K19)..................................................................347
RTH-K19).................................................................... 349
RTH-K19)...........................................................350
Fernsteuerbefehle
Einrichten von Messkurven
