Rohde & Schwarz Scope Rider RTH Benutzerhandbuch Seite 366

®
R&S Scope Rider RTH
REFCurve:SAVE
REFCurve:OPEN
REFCurve:DELete
REFCurve:SOURce <Source>
Selects the waveform to be taken as the reference waveform.
Parameter:
<Source>
REFCurve:UPDate
Creates the reference waveform from the source waveform.
Verwendung:
REFCurve:STATe <State>
Activates or deactivates the reference waveform.
Parameter:
<State>
REFCurve:POSition <Position>
Sets the vertical position of the reference waveform.
Parameter:
<Position>
REFCurve:NAME <Name>
Defines the path, filename and file format of the reference waveform file.
The default directory on the microSD card is /media/SD/Rohde-Schwarz/RTH/
ReferenceCurves, and /media/USB1/Rohde-Schwarz/RTH/ReferenceCurves
on USB flash drive.
Parameter:
<Name>
Beispiel:
REFCurve:SAVE
Saves the reference waveform. The target file is specified using REFCurve:NAME.
Verwendung:
Benutzerhandbuch 1326.1578.03 ─ 19
............................................................................................................366
........................................................................................................... 367
......................................................................................................... 367
C1 | C2 | C3 | C4 | M1
*RST: C1
Ereignis
ON | OFF
Std.-einheit: DIV
String
:REFCurve:NAME
'/media/SD/Rohde-Schwarz/RTH/ReferenceCurves/ref01.csv'
Ereignis
Fernsteuerbefehle
Messkurvenanalyse
366
