15.11.6 LIN (Option R&S RTH-K3)
● LIN-Konfigurationseinstellungen........................................................................... 488
● LIN-Trigger............................................................................................................ 490
● LIN-Decodierungsergebnisse................................................................................492
15.11.6.1 LIN-Konfigurationseinstellungen
BUS:LIN:DATA:SOURce
BUS:LIN:POLarity
BUS:LIN:BITRate
BUS:LIN:STANdard
BUS:LIN:DATA:THReshold
BUS:LIN:TECHnology
BUS:SETReflevels
BUS:LIN:DATA:SOURce <Channel>
Sets the source of the data line. All channel waveforms can be used.
Benutzerhandbuch 1326.1578.03 ─ 19
.
*
ERRor | OVERload | DATA | REMote | DOR
ERRor
When a node recognizes an error, it cancels transmission by
sending an error frame.
The instrument triggers seven bit periods after the end of the
error flag that is marked by a dominant-recessive edge.
OVERload
When a node needs a delay between data and/or remote fra-
mes, it sends an overload frame.
DATA
The data frame is the only frame for actual data transmission.
REMote
Remote frames are only available in the CAN protocol.
The remote frame initiates the transmission of data by another
node. The frame format is the same as that of data frames but
without the data field.
DOR
Data frames or remote frames initiate the transmission of data
by another node. The frame format is the same as that of data
frames.
*RST: DOR
Nur Abfrage
.................................................................................................488
.......................................................................................................... 489
...........................................................................................................489
........................................................................................................489
............................................................................................. 489
.................................................................................................... 490
......................................................................................................... 490
