R&S Scope Rider RTH
Verwendung:
BUS:SPI:SCLK:THReshold <ThresholdValue>
BUS:SPI:SSEL:THReshold <ThresholdValue>
BUS:SPI:MOSI:THReshold <ThresholdValue>
BUS:SPI:MISO:THReshold <ThresholdValue>
Set a user-defined value for the corresponding line if
USER.
Parameter:
<ThresholdValue>
BUS:SETReflevels
Sets the appropriate threshold or threshold for the selected serial protocol.
Verwendung:
BUS:SPI:WSIZe <WordLength>
Sets the number of bits in a word.
Parameter:
<WordLength>
BUS:SPI:ORDer <BitOrder>
Defines if the data of the words starts with MSB (most significant bit) or LSB (least sig-
nificant bit). Results are displayed in the specified order.
Parameter:
<BitOrder>
Benutzerhandbuch 1326.1578.03 ─ 19
CMOS
2.5 V
USER
Set a user-defined value for each line using the
BUS:SPI:<line>:THReshold commands.
*RST: TTL
SCPI-konform
Bereich: -400 bis 400
Inkrement: 1E-3
*RST: 1.4
Std.-einheit: V
Ereignis
WL4Bit | WL8Bit | WL12bit | WL16bit | WL20bit | WL24bit |
WL28bit | WL32bit
*RST: WL8Bit
LSBF | MSBF
*RST: MSBF
Fernsteuerbefehle
Protokollanalyse
BUS:SPI:TECHnology
is set to
