Rohde & Schwarz Scope Rider RTH Benutzerhandbuch Seite 352

®
R&S Scope Rider RTH
TRIGger:SPATtern:ORDer <BitOrder>
Defines if the data words start with MSBF (most significant bit first) or LSBF (least sig-
nificant bit first).
Parameter:
<BitOrder>
TRIGger:SPATtern:PATTern <Pattern>
Defines the serial pattern to be triggered on.
Parameter:
<Pattern>
Beispiel:
15.3.5.13 Timeout-Trigger (R&S RTH-K19)
TRIGger:TIMeout:RANGe
TRIGger:TIMeout:TIME
TRIGger:TIMeout:RANGe <TimeoutMode>
Selects the relation of the signal level to the trigger level, which is specified with
TRIGger:LEVel<m>:VALue
Parameter:
<TimeoutMode>
TRIGger:TIMeout:TIME <Time>
Sets the time limit for the timeout at which the instrument triggers.
Parameter:
<Time>
15.3.5.14 Intervalltrigger (R&S RTH-K19)
TRIGger:INTerval:SLOPe
TRIGger:INTerval:RANGe
TRIGger:INTerval:WIDTh
Benutzerhandbuch 1326.1578.03 ─ 19
LSBF | MSBF
*RST: MSBF
String that contains the pattern in binary format. The parameter
accepts the bit value X (don't care).
TRIGger:SPATtern:PATTern '11001100'
TRIGger:SPATtern:PATTern '110011XX'
............................................................................................... 352
.................................................................................................. 352
HIGH | LOW | EITHer
*RST: HIGH
Bereich: 100E-12 bis 10000
Inkrement: 100E-9
*RST: 5E-9
Std.-einheit: s
................................................................................................353
............................................................................................... 353
................................................................................................ 353
Fernsteuerbefehle
Einrichten von Messkurven
352
