Parameter:
<Range>
Verwendung:
METer:CONFigure:CURRent:AC
METer:CONFigure:CURRent:DC
Sets the internal parameters and configures the range for current measurements.
You need an external shunt resistor or I/U converter for current measurement.
Parameter:
<Range>
Verwendung:
METer:CONFigure:FREQuency
Configures the frequency measurement and sets voltage autoranging.
To set a fixed voltage range, use
UPPer.
Verwendung:
METer:CONFigure:RESistance
Sets the internal parameters and configures the range for resistance measurements.
Benutzerhandbuch 1326.1578.03 ─ 19
<numeric value> | 'AUTO' | MIN | MAX | DEF
<numeric value>
The instrument has fixed measurement ranges: 10 nF|100 nF|
1 μF|10 μF|100 μF|1 mF|10 mF.
You can enter any value between the minimum and maximum
value. The instrument uses the next suitable range.
Bereich: 10 nF bis 10 mF
*RST: 10 nF
Nur Einstellung
<numeric value> | 'AUTO' | MIN | MAX | DEF
<numeric value>
The instrument has fixed measurement ranges: 1 A|10 A|100 A|
1000 A.
You can enter any value between the minimum and maximum
value. The instrument uses the next suitable range.
Bereich: 1 bis 1000
*RST: 1
Std.-einheit: A
Nur Einstellung
METer:SENSe:FREQuency:VOLTage:RANGe:
