R&S Scope Rider RTH
TRIGger:PATTern:STATe:COMBination <ChCombination>
Sets the logical combination for all active channels. The required state of each channel
is defined by TRIGger:STATe:CHANnel<m>.
Parameter:
<ChCombination>
TRIGger:PATTern:WIDTh:RANGe <Condition>
Adds additional time limitation to the pattern defined by
CHANnel<m>]
Parameter:
<Condition>
TRIGger:PATTern:TIMeout[:TIME] <Time>
Sets a minimum time during which the signals match the pattern definition defined by
TRIGger:PATTern:STATe[:CHANnel<m>]
COMBination.
The command is required if
Benutzerhandbuch 1326.1578.03 ─ 19
*RST: DONTcare
AND | OR
*RST: AND
and TRIGger:PATTern:STATe:COMBination.
ANY | TIMeout | LONGer | SHORter | EQUal | NEQual |
WITHin | OUTSide
ANY
Triggers on all runts fulfilling the level condition, without time
limitation.
Triggers if the signals match the pattern definition for a minimum
time, which is specified by
TIME].
LONGer | SHORter
Triggers on pulses shorter or longer than a runt width that is
defined by TRIGger:RUNT:WIDTh.
EQUal | NEQual
Triggers pulses with a width equal or unequal to a given width
and an optional tolerance defined by
and Runt-Breite (Runt Width)
WITHin | OUTSide
Triggers on pulses inside or outside a given range.
*RST: LONGer

TRIGger:PATTern:WIDTh:RANGe

Fernsteuerbefehle
Einrichten von Messkurven
TRIGger:PATTern:STATe[:
TRIGger:PATTern:TIMeout[:
TRIGger:RUNT:WIDTh
and
TRIGger:PATTern:STATe:
is set to TIMeout.
342
