R&S Scope Rider RTH
Parameter:
<Level>
TRIGger:WINDow:TIME <Condition>
Selects how the time limit of the window is defined.
Parameter:
<Condition>
TRIGger:WINDow:RANGe <LevelRangeMode>
Selects how the signal run is compared with the window:
Parameter:
<LevelRangeMode> ENTer | EXIT | WITHin | OUTSide
TRIGger:WINDow:WIDTh <Duration>
Sets the width for comparison ranges LONGer, SHORter, EQUal, NEQual.
Benutzerhandbuch 1326.1578.03 ─ 19
Bereich: -10 bis 10
Inkrement: 1E-3
*RST: 0
Std.-einheit: V
LONGer | SHORter | EQUal | NEQual | WITHin | OUTSide
LONGer | SHORter
Triggers if the signal crosses the upper or lower level after/
before the time „Width" defined by TRIGger:WINDow:WIDTh.
EQUal | NEQual
Triggers if the signal stays inside or outside the vertical window
limits for a time equal/uneuqal to „Width" „±Tolerance" defined
by

TRIGger:WINDow:WIDTh

WITHin
Triggers if the signal stays inside or outside the vertical window
limits for a time ≥„Min Width" AND ≤ „Max Width".
OUTSide
Triggers if the signal stays inside or outside the vertical window
limits for a time < „Min Width" OR > „Max Width".
*RST: LONGer
ENTer | EXIT
Triggers when the signal crosses the upper or lower level and
thus enters/leaves the window made up of these two levels
which are defined by
TRIGger:LEVel<m>:WINDow:UPPer
and TRIGger:LEVel<m>:WINDow:LOWer.
WITHin | OUTSide
Triggers if the signal stays between/above the upper and lower
level for a specified time. The time is defined by
WINDow:TIME.
*RST: ENTer
Fernsteuerbefehle
Einrichten von Messkurven
and TRIGger:WINDow:DELTa.
TRIGger:
