R&S Scope Rider RTH
Beispiel:
Verwendung:
HARMonic:RESult<m>:HARMonics<n>:LIMViolation?
Queries whether the calculated level for the specified harmonic exceeds the defined.
Note: Only if a limit value is defined, a limit check is performed for the harmonic (see
HARMonic:RESult<m>:HARMonics<n>:LIMCheck?
Tip: To query the result of the limit check for the entire signal, use
RESult<m>:LIMViolation?
Suffix:
<m>
<n>
Rückgabewerte:
<State>
Beispiel:
Verwendung:
Benutzerhandbuch 1326.1578.03 ─ 19
HARM:LIM:TYPE EN50160
HARM:RES1:HARM2:LIMC?
//Result: 1
HARM:RES1:HARM2:LIM?
//Result: 2%
HARM:RES1:HARM2:LIMV?
//Result: 0
Nur Abfrage
auf Seite 399.
.
1|2 (RTH1002) , 1..4 (RTH1004)
1..64
Order of harmonic (possibly restricted, see
RESult<m>:NOHarmonics?).
ON | OFF
ON
A limit violation occurred - the limit was exceeded.
OFF
No limit violation occurred.
HARM:LIM:TYPE EN50160
HARM:RES1:HARM2:LIMC?
//Result: 1
//The EN50160 defines a limit of 2% for the
//second order harmonic.
HARM:RES1:HARM2:LIM?
//Result: 2
HARM:RES1:HARM2:LIMV?
//Result: 1
//The calculated value exceeds the defined
// limit for the second harmonic.
HARM:RES1:LIMV?
//Result: 1
//Since the limit check for the second harmonic
// failed, the limit check for the entire
// signal failed.
Nur Abfrage
Fernsteuerbefehle
Spektrumanalyse
auf Seite 396).
HARMonic:
HARMonic:
