R&S Scope Rider RTH
Parameter:
<Slope>
TRIGger:SLEW:RANGe <Condition>
Defines the time limits of the slew rate.
Parameter:
<Condition>
TRIGger:SLEW:RATE <Duration>
Sets the slew rate for comparison ranges EQUal, UNEQual, SHORter, and LONGer.
See TRIGger:SLEW:RANGe.
Parameter:
<Duration>
TRIGger:SLEW:DELTa <Tolerance>
Sets a range Δt to the specified slew rate, which is defined using
RATE.
Parameter:
<Tolerance>
TRIGger:SLEW:MINWidth <MinDuration>
Sets the lower time limit of the transition time for comparisons WITHin and OUTSide.
Benutzerhandbuch 1326.1578.03 ─ 19
POSitive | NEGative | EITHer
*RST: POSitive
LONGer | SHORter | EQUal | NEQual | WITHin | OUTSide
LONGer | SHORter
Triggers on pulses shorter or longer than a runt width that is set
using TRIGger:SLEW:RATE.
EQUal | NEQual
Triggers on pulses equal or not equal a given runt width that is
set using TRIGger:SLEW:RATE. In addition, a tolerance can be
set around the specified width using TRIGger:RUNT:DELTa.
WITHin | OUTSide
Triggers on pulses inside or outside a given range.
*RST: LONGer
Bereich: 800E-12 bis 10000
Inkrement: 100E-9
*RST: 5E-9
Std.-einheit: s
Bereich: 0 bis 5000
Inkrement: 500E-12
*RST: 0
Std.-einheit: s
Fernsteuerbefehle
Einrichten von Messkurven
TRIGger:SLEW:
