15.11.5.2
CAN-Trigger
TRIGger:CAN:ACKerror <AckError>
An acknowledgment error occurs when the transmitter does not receive an acknow-
ledgment - a dominant bit during the Ack slot.
Parameter:
<AckError>
TRIGger:CAN:BITSterror <StuffBitError>
A stuff error occurs when the 6th consecutive equal bit level in the mentioned fields is
detected.
Parameter:
<StuffBitError>
Benutzerhandbuch 1326.1578.03 ─ 19
ISO
Signals are decoded according to the ISO CAN FD protocol.
This protocol has an additional stuff count field before the CRC
sequence.
NISO
Non-ISO. Signals are decoded according to the Bosch CAN FD
protocol.
*RST:
ISO
..................................................................................................477
................................................................................................ 477
................................................................................................. 478
....................................................................................................... 478
..............................................................................................478
...............................................................................................478
..................................................................................................... 478
............................................................................................... 479
................................................................................................. 479
...................................................................................................... 479
.......................................................................................................480
.............................................................................................. 480
......................................................................................481
............................................................................................... 481
.............................................................................................. 481
........................................................................................481
ON | OFF
*RST:
ON
ON | OFF
*RST:
ON
