8.4.7 [Analog inputs (1.2.5)
Fig. 25 Analog inputs
Description
The display shows an overview of the analog inputs and the
measured values of each input. See sections
inputs (4.3.8), 8.7.29 Analog inputs (4.3.8.1 - 4.3.8.7)
8.7.30 Analog inputs and measured value (4.3.8.1.1 -

8.4.8 Log graph (1.2.6)

Fig. 26 Log graph
Description
The display shows logged data stored in the controller.
Select log values in the Log values (4.4.9)
can be shown, and the time scale can be changed.
Setting via operating panel
Status > System > Log graph
1. Set as a percentage:
• Zoom begins at
• Zoom ends at
2. Select values to be shown.
20

8.4.9 Battery status (1.2.7)

Description
The display shows the status of the backup battery, if installed.
8.7.28 Analog
and
4.3.8.7.1).

8.4.10 Status of remote sensors (1.2.8)

display. Various values
Fig. 27 Battery status
The battery only supplies CU 354 with backup power.
Fig. 28 Sofrel status
Fig. 29 XiLog status
