8.3 Status and fault indications

8.3.1 Status indications

The status is shown as text in the display (see also section
8. Control panel) and by means of indicator lights in the control
panel or indicator lights in the cabinet door. The following table
gives an overview of status indications.
Status
The pump was in automatic mode and was
stopped though a request from a pressure
switch was still present.
The pump can only be started manually.
The pump is running (automatic start via
pressure switch or manual start).
The starting cause is shown in the upper
right corner of the display:
Press1 = Pressure switch 1
Press2 = Pressure switch 2
Level = Level in storage tank too low
Extern = External input
TestEm = Test/emergency operation via
[ST1] or [ST2]
Manual = Manual operation via [Start
engine]
Emerg. = Emergency operation via [SE1]
or [SE2]
Mains voltage OK.
Calibration prompt (at startup).
Engine start during automatic operation.
Indication of battery set (B1), number of
start attempts (3) and start trigger (Press1).
(Between starts, the message "Engine off"
is shown in the top line of the display.)
Engine start during manual operation.
(When the engine has started, the speed is
indicated in the upper left corner of the
display.)
The louvres are open.
The ventilator is running.
Indicator light
Status
PUMP
On SWITCHED
PUMP
On
RUNNING
POWER
On
SUPPLY
- -
- -
- -
H4
On Louvres open
H5
On Ventilator on

Display text

(status display)
Text
Engine off
T = 40 °C Oil = 3b
00000H Fuel = 100 %
OFF
B1 = 24 V B2 = 24 V
1700 rpm Press1
T = 80 °C Oil = 3b
00000H Fuel = 100 %
B1 = 24 V B2 = 24 V
Engine off
T = 20 °C Oil = 0b
00000H Fuel = 100 %
B1 = 24 V B2 = 24 V
?CAL?
T = 20 °C Oil = 0b
-
00000H Fuel = 100 %
B1 = 24 V B2 = 24 V
Star.B1=3 Press1
T = 20 °C Oil = 0b
-
00000H Fuel = 100 %
B1 = 24 V B2 = 24 V
Engine off Manual
T = 20 °C Oil = 0b
-
00000H Fuel = 100 %
B1 = 24 V B2 = 24 V
Output
activated
DO7 and DO8
DO3 and DO4
DO5
DO8
DO10
DO11
