Liquid level in priming tank
The level in the priming tank can be monitored by installing a
level switch. If the level falls under a certain value, digital output
DO12 will be activated. Depending on version, the engine may be
started. "Level" will appear in the top line of the display as the
cause for starting.
The sensor cable is monitored for wire breakage and short-circuit
(closed-circuit resistance 392 Ohm, open-circuit resistance
1100 ohm). In case of sensor cable fault, indicator light
"CONNECTION SENSOR ALARM" will light up. Digital output
DO2 will also be activated. When the fault no longer exists, the
fault indication will be reset automatically.
Diesel or oil leakage
The controller can be equipped with a leak monitoring device to
detect if diesel is leaking from the fuel tank or oil is leaking from
the engine (and collected in a pan underneath the pump set).
Leak monitoring takes place by means of an evaluation device
and a probe. The evaluation device is installed separately outside
the control cabinet.

6. Identification

6.1 Nameplate

The controller can be identified by means of the nameplate.
Type: Control FS 1 Dieselmotor 24 V/230 V
Produkt Nr.: 96750712
Serien Nr.: 3000213230
Versorgungsspannung: 230V
Batteriespannung: 24V
Batteriekapazität: 120AH
VdS-Nr.: G
Made in Germany P1 0824
Fig. 3 Nameplate

6.2 Type key

Example Control FS 1 Diesel engine 24 V /230 V VdS
Type range
Application:
FS: for fire pump sets
Number of pumps
Diesel engine
Battery voltage:
24 V
Supply voltage:
230 V
VdS approval
Batt.-typ: Blei
Schutzart: IP54
Frequenz: 50 Hz
Anschlussleistung: 3 KW
VdS

7. Technical data

Control cabinet: Sheet steel, red.
Enclosure class: IP54.
Dimensions w x h x d: 760 x 760 x 210.
Weight: 57 kg.
Supply voltage: 1 x 230 VAC (+ 10 %/- 15 %),
50/60 Hz, PE.
Max. current consumption: 13 A.
Backup fuse: Max. 20 A.
Connecting terminals: L1, N = 2.5 - 6 mm
EMC noise emission: According to EN 61000-6-3.
EMC noise immunity: According to EN 61000-6-2.
Ambient temperature: -5 to 40 °C.
Production country: Germany.
Inputs
The controller has five analog inputs and seven digital inputs, five
of which are monitored. See tables below. The tables also state
terminal designations and, for digital inputs, the status when
activated.
Analog inputs
Analog input
Fuel level
Oil pressure
Engine temperature
Speed (generator)
Speed sensor
Electrical data of analog inputs
Voltage class: None.
Insulation voltage: 50 V (in relation to earth).
Insulation test voltage: None.
Input resistance: 1.5 kOhm.
Input resolution: 19.5 mV.
Accuracy at 25 °C: ± 0.4 %.
Resolution: 8 bits.
Integral time. 150 ms.
Reading interval: 40 ms.
The analog inputs are not short-circuit-proof.
Data of the pulse input to which the speed sensor can be
connected for monitoring of the generator:
Max. frequency: 10 kHz.
Input resistance: 4.85 kOhm.
Input voltage: ± 30 V.
Input current: 7 mA.
Digital inputs
Digital input
External fault*/**
Oil pressure switch
Engine temperature
Fuel valve position*
Level switch, priming tank */**
Pressure switch 1*
Pressure switch 2*
* Monitored.
** Optional.
2
.
Terminal
X3, 20
X3, 19
X3, 18
X3, 15
X3, 21 + 22
Position when
Terminal
activated
X3, 1 + 2
X3, 3 Closed
X3, 4 Closed
X3, 5 + 6 Open
X3, 7 + 8 Closed
X3, 9 + 10 Closed
X3, 11 + 12 Closed
