8.2.1 Language
Menu Parameters
Language
German
In display "Language", you can select one of the following
languages:
• German
• French
• English
• Polish
• Spanish.
Factory setting: German.
8.2.2 Password
Menu Parameters
Password
0
In this display, a password can be entered in order to change
further parameters. These parameters may only be changed by
Grundfos employees.
8.2.3 Calibration of engine speed
If the controller is part of a complete fire pump set, calibration of
the speed display is carried out at the factory. If the controller is
delivered separately, a request for speed calibration will appear in
the first line of the status display during startup:
?CAL?
T = 40 °C Oil = 10b
00000H Fuel = 100 %
B1 = 24 V B2 = 24 V
Calibration procedure:
1. Measure the operating speed directly at the diesel engine with
a suitable measuring device. Set the operating speed of the
engine to the next full hundred step (e.g. 1700 rpm). Setting of
operating speed is described in the installation and operating
instructions for the diesel engine.
2. Press to enter the selection mode. The green indicator
light next to lights up.
3. Select the following setting display using
Menu Parameters
Cal. rev. counter
1700 rpm
4. Press to change the speed. The green indicator light next
to starts flashing.
5. Adjust the speed by pressing
to 4000 rpm, adjustable in steps of 100).
6. Save the parameter value by pressing
indicator light next to is now on.
7. Press to activate the changes and return to the status
display.
After the automatic calibration, the parameter value in display
"Cal. engine on" is automatically reset to "No":
Menu Parameters
Cal. Engine on
No
The "?CAL?" symbol flashes in the display during the automatic
calibration process. The calibration process can take up to
30 seconds. When the calibration process is completed, the
current speed appears instead of the flashing symbol.
8. After calibration, the operating speed of the diesel engine
must be reset to the original nominal speed.
The same calibration process must be carried out if the speed is
determined using an optional speed sensor. The two
measurements cannot, however, be carried out at the same time.
12
or :
or (setting range 1000
. The green
8.2.4 Number of start attempts
Menu Parameters
Starting B1&B2
6 starts
This display shows the number of start attempts. It is not possible
to change this parameter value.
Factory setting: 6.
8.2.5 Start attempt interval
Menu Parameters
Start time off
7.0 sec.
In this display, the interval between two start attempts can be set
for automatic operation.
Setting range: 5.0 to 10.0 seconds in steps of 0.1 second.
Factory setting: 7.0 seconds.
In order to speed up the setting procedure, the
parameter value can also be changed in steps of
Note
1.0 seconds by keeping
8.2.6 Duration of start attempts
Menu Parameters
Start time on
5.0 sec.
In this display, the number of seconds for which the starting relay
is activated in order to start the diesel engine can be set for
automatic operation. The duration of the start attempt is thus
specified.
Setting range: 5.0 to 10.0 seconds in steps of 0.1 second.
Factory setting: 5.0 seconds.
In order to speed up the setting procedure, the
parameter value can also be changed in steps of
Note
1.0 seconds by keeping
8.2.7 Duration of stop attempts
Menu Parameters
Stop time
10 sec.
In this display, you can set the number of seconds for which the
stop valve is activated in order to stop the engine when [S2] has
been pressed.
Setting range: 5.0 to 25.0 seconds in steps of 0.1 second.
Factory setting: 10 seconds.
In order to speed up the setting procedure, the
parameter value can also be changed in steps of
Note
1.0 seconds by keeping
8.2.8 Contrast
The display contrast can be adjusted by pressing
or (brighter) in the status display.
or pressed.
or pressed.
or pressed.
(darker)
