Quad LFO A-143-3
2. Overview
3
1
2
Fig. 2: A-143-3 front panel
2
System A-100
Controls:
1
2
!
3
§
Outputs:
"
!
"
§
The controls and outputs are the same for all four sub-units.
Module width: 14 HP / 70.8 mm
Module current: 70 mA
Frequ. : frequency control
Range: frequency range switch
: LED control
: triangle output
: rectangle output
: sawtooth output
