Network Setting - Balluff BIS U-6127-081-1 4-06-ST36 Betriebsanleitung

BIS U-6127-081-1_4-06-ST36
Processor unit
7
Startup and operation (continued)

Network setting

The settings for the Ethernet interface of the BIS U-6127
(see Fig. 7-11) are called up in the c
under n (see Fig. 7-9 on page 36).
etwoRk
Fig. 7-11: Network settings
In the delivery state, the static assignment of an IP address
is activated (see Fig. 7-11). However, this setting can also
be changed to automatic assignment of an IP address via
DHCP (a). If static IP address assignment is activated, the
ip a (b) and the S
ddReSS uBnet
newly set IP address can be entered on the type plate of
the device by the user. In addition, the settings for the IP
addresses of a g (d) for external network access and
ateway
the desired primary (e) and secondary (f) DNS name server
are also available. If a server with NTP functionality
(network time protocol) is to be used for setting the time,
this must be entered in the input field (g). Either an IP
address or a domain name (e.g. time.google.com) can be
entered here.
With S (h) the settings are saved on the device, with
et
R (i) they are discarded or updated.
efReSh
To activate the settings made on the device, a restart is
necessary, which can be triggered with R
above parameters require an
parameters.
The following settings are used as configuration values in
the standard configuration:
Configuration element
IP assignment
IP address
Subnet mask
Gateway
DNS IP 1
DNS IP 2
NTP server
www.balluff.com
menu
onfiguRation
m (c) can be set. The
aSk
(j). All of the
eBoot
level to change/update
admin
Default value
Static
192.168.10.2
255.255.255.0
0.0.0.0
0.0.0.0
0.0.0.0
RFID settings
The RFID settings (see Fig. 7-12) are called up in the
c menu under Rfid (see Fig. 7-9 on
onfiguRation
page 36).
Fig. 7-12: RFID settings
There are five tabs, under each of which different RFID
settings can be made:
– Basic UHF
– Antennas & power
– UHF extended
– Filter options
– Formatted tag data
All parameters can be read with any access authorization.
However, to change parameter values, certain access
rights must be present.
Basic UHF
Fig. 7-13: Basic UHF
To change the settings, at least the e
authorization level is required.
Parameters for general operation:
– (a) Initial Q-value/expected number of tags (parameter
0002 ) see page 56
hex
– (b) TID length (Parameter 0004
page 61
– (c) Number of read attempts (Parameter 000A
page 61
– (d) Activate BlockWrite (Parameter 000D
page 61
– (e) Max. write length (Parameter 000D
page 62
– (f) Max. read length (Parameter 000E
– (g) Active channels (Parameter 000B
xpeRt
) in bytes, see
hex
) see
hex
) see
hex
) see
hex
) see page 62
hex
) see page 59
hex
