Processor unit
8
007 protocol (continued)
Command identifier 'p': Change transmitting power
Setting the transmitting power (ERP/EIRP) as ¼-dBm
value. The transmitting power influences the maximum
range of the detection range of the antenna.
Example:
Set a transmitting power of 23 dBm (200 mW):
23 dBm
=92
¼ dBm
92 = 5C
hex
The following values must be transferred for this purpose:
– Transmitting power 1st character: '5'
– Transmitting power 2nd character: 'C'
The maximum permissible transmitting power
depends on the antenna used and on the radio
regulations applicable in the respective country. For
detailed information, see chapter 5 on page 18
and the data sheet of the antenna used.
Byte Length Command
element
00 1 Command
recognition
01 1 Antenna
number (ASCII)
02...03 2 Transmitting
power (ASCII
hex)
04 1 BCC
Status message:
Byte Length Command
element
00 1 Status
01 1 Status code
If the status message is positive, the new transmitting
power is accepted with <STX>.
Byte Length Command
element
00 1 Control
command
Status message:
Byte Length Command
element
00 1 Status
01 1 Status code
www.balluff.com
Command identifier 'G': Read device parameters
Reading out general and antenna-related parameter data.
For a detailed parameter description, see chapter 7.3 on
page 49.
Byte
00
01
02...05 4
06
The positive status message contains the requested
parameter data.
Value range
Byte
'p'
00
01
'0': All antennas
'1'...'4': Single
02
antenna
"00"..."FF"
03...04 1
00 ...FF
hex hex
05...08 2
Value range
09
<ACK> or <NAK>
...
See table Status
codes on page
Last
94
byte
If the data cannot be provided, a negative status message
follows.
Value range
Byte
<STX> 00
01
Value range
02
<ACK> or <NAK>
See table Status
codes on page
94
Length Command
element
1 Command
identifier (ASCII)
1 Antenna number
(ASCII)
Parameter
number (ASCII
hex)
1 BCC
Length Command
element
1 Status
1 Reserved (ASCII)
1 Antenna number
(ASCII)
Number of bytes
(ASCII)
Parameter
number (ASCII
hex)
4 Data
... ...
1 BCC
Length Command
element
1 Status
1 Status code
1 BCC
english
Value range
'G'
'1': Antenna 1
'2': Antenna 2
'3': Antenna 3
'4': Antenna 4
"0000"..."FFFF"
00 ...FF
hex hex
Value range
<ACK>
'0'
'0': General
'1': Antenna 1
'2': Antenna 2
'3': Antenna 3
'4': Antenna 4
"00"..."99"
"0000"..."FFFF"
00 ...FF
hex hex
00 ...FF
hex hex
00 ...FF
hex hex
Value range
<NAK>
See table Status
codes on page
94
00 ...FF
hex hex
