Processor unit
5
Technical data (continued)
5.4
Ambient conditions
Operating temperature
−20...+55 °C
Storage temperature
−20...+60 °C
Vibration/shock
EN 60068 part 2-6/27
Degree of protection as
IP65
per IEC 60529
5.5
Connectors ANT1...ANT4
Characteristic impedance
50 ohms
Output power max.
1.4 W (31.5 dBm) or
1 W (30 dBm), depending on
country variant
5.6
IO-Link connection
IO-Link revision
1.1
Power supply for IO-Link,
VS – VD (VD = 0.5...3 V,
I/O modules (output)
load-dependent)
1.7 A max. (protected by
overcurrent shutoff)
Data rate (IO-Link)
COM1
4.8 kBit/s
COM2
38.4 kBit/s
COM3
230.4 kBit/s
Pin 2/Pin 4 (I/O mode)
VS – VD (VD = 0.5 V...3 V,
Input/Output
load dependent) 2 A max.
Pin 4 (IO-Link mode)
C/Q IO-Link data transmission
Cable type
Unshielded, 4-wire
Cable length max.
20 m (in IO-Link mode)
When using IO-Link RFID read/write heads in electromagnetically
1)
disturbed environments, the use of shielded cables is recommended.
NOTICE
Exceeding the maximum current consumption
If the maximum current consumption is exceeded, the
processor unit and connected system components may
be damaged.
► During operation, make sure that the total current
carried by the Power terminal does not exceed 3 A.
► The voltage output (L+) on the IO-Link port and
digital outputs (I/O) are supplied via the Power
connection. The sum of the partial currents of these
pins, must not exceed a maximum current of 2 A.
www.balluff.com
5.7
Ethernet TCP/IP connection
Ethernet standards accor-
ding to IEEE 802.3-2008
(up to 1 Gigabit)
Protocol
Data rate max.
Cable types
Cable length max.
The use of repeaters is recommended for data
transmission over longer distances.
5.8
Service connection (USB)
USB version
Data rate max.
Cable type
Cable length max.
5.9
Data carrier
ISO
EPCglobal
Multi-tagging
(maximum number of data
carriers)
1)
5.10
Display elements at a glance
RF active
Tag present
Power/Status
User
Antenna 1...Antenna 4
Link
Activity
IO-Link 0
IO-Link 1
For a detailed description of the display ele-
ments, see chapter 3.8 on page 12.
10BASE-T
100BASE-TX
1000BASE-T
TCP/IP
OPC UA
10/100/1000 Mbit/s
CAT3 (only 10BASE-T)
CAT5
100 m
2.0
480 Mbit/s
Shielded, 5-wire
5 m
18000-63
Class 1 Generation 2
TM
500
Blue
Yellow
Red, Yellow, Green
Red, Yellow, Green
Yellow
Green
Yellow
Red, Yellow, Green
Red, Yellow
