Processor unit
7
Startup and operation (continued)
Prefix for ReadMultipleTagDataFormatted (default)
Parameter-ID: 0026
hex
UHF-Manager: Menu: Device settings > Parameters...
> Read > Write
OPC UA: SetTagDataFormatted/GetTagDataFor-
matted method
Webserver: Configuration > RFID > Formatted tag
data
Defines the default prefix for the FormattedTagData
function to be used after switching on or restarting the
processor unit.
Adjustable values:
Length Permissi- Factory setting
[byte] ble
values
007: String "Begin#0d#0a" Text
0...99 "Begin" with CR LF
Web and
OPC UA:
0...1024
Suffix for ReadMultipleTagDataFormatted (default)
Parameter-ID: 0027
hex
UHF-Manager: Menu: Device settings > Parameters...
> Read > Write
OPC UA: SetTagDataFormatted/GetTagDataFor-
matted method
Webserver: Configuration > RFID > Formatted tag
data
Defines the default suffix for the FormattedTagData
function to be used after switching on or restarting the
processor unit.
Adjustable values:
Length Permissi- Factory setting
[byte] ble
values
007: String "End#0d#0a" Text
0...99 "End" with CR LF
Web and
OPC UA:
0...1024
80 english
Calculation format for signature generation (default)
Parameter-ID:
UHF-Manager:
OPC UA:
Webserver:
Defines the data areas of the data carrier that are included
in the calculation for generating and verifying the signature,
usually the EPC and the TID, possibly also part of the user
data area for data carriers with larger memory.
The area where the signature itself is stored (currently the
first 64 bytes of the user data area) must not be included.
The specification must be exactly the same for signature
generation and signature verification, otherwise the
Meaning
signature cannot be recognized as valid.
The specifications are generated using the same system
as for the formatted output, although it is not useful to
Prefix for
specify format modifiers (X, x, or d).
ReadMul-
Examples:
tipleTag-
12 bytes of the EPC and 12 bytes of the TID are to be
DataFor-
included:
matted
Calculation format: "%E[0.12]%T[0.12]"
12 bytes of the EPC and 12 bytes of the TID and 16 bytes
of the user data area starting at address 64 are to be
included:
Calculation format: "%E[0.12]%T[0.12]%U[64.16]"
For details on signature generation and verification,
see Data security on page 11.
Adjustable values:
Length
[byte]
007:
0...99
Web and
OPC UA:
0...1024
Meaning
Suffix for
ReadMul-
tipleTag-
DataFor-
matted
0028
hex
–
SetTagSignatureFormat/GetTagSigna-
tureFormat method
Configuration > RFID > UHF extended
Permissi- Factory setting
ble
values
String "%E[0.12]%T[0.8]"
12 bytes EPC +
8 bytes TID
Meaning
Calcula-
tion
format for
signature
generation
