BIS U-6127-081-1_4-06-ST36
Processor unit
7
Startup and operation (continued)
7.2
Web server
A browser (e.g. Google Chrome) is required to connect to
the web server of the device via TCP/IP. In the address
line, enter the IP address of the device preceded by
"http://" and followed by "/" (e.g. http://192.168.10.2/).
The BIS U-6127 web server application provides an
interface to access the device information. The device
settings can be changed and adapted as required.
Fig. 7-4 shows the menu bar of the web server with seven
main menus, which are described below.
1
Home
2
Log in/log out
3
Language setting
4
RFID
Fig. 7-4:
Main menu
7.2.1
Home
Fig. 7-5 shows the home page of the web server
application.
The interface is divided into two parts:
–
On the left side there is device information (not
changeable).
–
On the right side the device is illustrated and shows the
current state of the LEDs.
Fig. 7-5:
Homepage
www.balluff.com
5
Setup
6
Logbook
7
Info
7.2.2
Log in/Log out
A majority of the display functions of the device websites
also work without logging in. However, the e
role is required to change many settings. It is then
necessary to log in via the menu item l
Logging in
1. In the u
field, enter the name under which you
SeRname
want to log in to the BIS U-6127 device.
2. Under p
, enter the password valid for this user.
aSSwoRd
By clicking on the eye icon next to the dialog box, the
characters can be made visible.
Fig. 7-6:
Entry dialog for entering user name and password
Logging out
If the login was successful, the field (2) of the main menu
shown in Fig. 7-4 displays the text l
Users are automatically logged out of the system after a
period of inactivity of 15 minutes and a new login is
required. After 24 hours at the latest, you must log in
again.
Factory preconfigured users
At the first startup, certain standard user profiles are
available on the system ex factory (see the following table).
The default settings should be changed
during the first configuration for security
reasons!
You can add your own users and provide them
with appropriate permissions.
or a
xpeRt
dmin
.
og in
.
og out
english
33
