Processor unit
8
007 protocol (continued)
Command identifier 'l': Lock
The l command can be used to lock memory areas
ock
(RES, EPC, TID, USER) of a UHF data carrier against write
or read accesses, as well as any other accesses.
Depending on the security level, the memory areas can
only be password-protected or completely locked.
The m and a fields are used to specify which
aSk ction
memory areas are to receive a new l
this should look like. By using bit masks, the l
several memory areas can be changed at the same time.
Before executing the l command, the data carrier must
ock
be selected and the access password (a
for the selected tag must be written to parameter 1004
(see Memory bank on page 54).
For selecting data carriers (see Command
identifier 'z': Select data carrier (Select) on
page 105).
To set an access password for a data carrier,
write to byte address 4...7 of the R
memory bank, see Command identifier 'F':
Write data carrier, extended (>1024 bytes) on
page 114.
To transfer the password to access the data
carrier and execute the l
see Command identifier 'E': Change device
parameters on page 98 (parameter no:
1002 ).
hex
Mask and action
m : Bit mask (16 bits) used to define which memory
aSk
areas are to be influenced by the a
status of the EPC, TID and USER memory areas and the
area where passwords are stored can be locked/unlocked
independently.
– 0: Memory area is not affected by the a
– 1: Memory area is influenced by the a
a : Bit mask (16 bits) used to define the l
ction
the memory areas specified by m
Bit no. 15 14 13 12
Mask Not used
Action Not used
Bit no. 7 6 5 4
Mask Access EPC
password
Action Lock- Lock-
Status Status
www.balluff.com
status and what
ock
status of
ock
pw) valid
cceSS
hex
eSeRved
command,
ock
field. The l
ction ock
field
ction
field
ction
status of
ock
.
aSk
11 10 9 8
Kill PW
Status
3 2 1 0
TID USER
Lock- Lock-
Status Status
Lock status of the memory areas EPC, TID, USER
The TID memory area is always write-protected
regardless of the lock status and can only be
read.
Status Reading Writing
possible possible
00 Yes Yes
01 Yes Yes
10 Yes With access
password
11 Yes Locked
Lock status for contents of Reserved memory area
(Access PW/Kill PW)
Status Reading Writing
possible possible
00 Yes Yes
01 Yes Yes
10 With access With access
password password
11 Locked Locked
Execution of Lock command
Byte Length Command
element
00 1 Command
identifier (ASCII)
01 1 Antenna number
(ASCII)
02...05 4 Mask (ASCII hex)
06...09 4 Action (ASCII
hex)
10 1 BCC
Status message:
Byte Length Command
element
00 1 Status
01 1 Status code
Status can be
changed
Yes
No
Yes
No
Status can be
changed
Yes
No
Yes
No
Value range
'l'
'0': All active
antennas
'1'...'4': Single
antenna
"0000"..."03FF"
"0000"..."03FF"
00 ...FF
hex hex
Value range
<ACK> or NAK>
See Status codes
on page 94
english 119
