Processor unit
7
Startup and operation (continued)
Prefix for ReadMultipleTagDataFormatted
Parameter-ID: 1009
hex
UHF-Manager: –
OPC UA: SetTagDataFormat/GetTagDataFormat
method
Webserver: –
Prefix for ReadMultipleTagDataFormatted specifies the text
or byte sequence to be prepended to the data defined
with ReadMultipleTagDataFormatted.
Adjustable values:
Length Permissi- Factory setting
[byte] ble
values
007: String "Begin#0d#0a" Text
0...99 "Begin" with CR LF
Web and
OPC UA:
0...1024
Suffix for ReadMultipleTagDataFormatted
Parameter-ID: 100A
hex
UHF-Manager: –
OPC UA: SetTagDataFormat/GetTagDataFormat
method
Webserver: –
Suffix for ReadMultipleTagDataFormatted specifies the text
or byte sequence to be appended to the data defined with
ReadMultipleTagDataFormatted.
Adjustable values:
Length Permissi- Factory setting
[byte] ble
values
007: String "End#0d#0a" Text
0...99 "End" with CR LF
Web and
OPC UA:
0...1024
www.balluff.com
Calculation format for signature generation
Parameter-ID:
UHF-Manager:
OPC UA:
Webserver:
Defines the data areas of the data carrier that are included
in the calculation for generating and verifying the signature
(usually the EPC and the TID, possibly also part of the user
data area for data carriers with larger memory). The area
where the signature itself is stored (currently the first
64 bytes of the user data area) must not be included.
Meaning
The specification must be exactly the same for signature
generation and signature verification, otherwise the
signature cannot be recognized as valid.
Prefix for
The specifications are generated using the same system
ReadMul-
as for the formatted output, although it is not useful to
tipleTag-
specify format modifiers (X, x, or d).
DataFor-
Examples:
matted
12 bytes of the EPC and 12 bytes of the TID are to be
included:
Calculation format: "%E[0.12]%T[0.12]"
12 bytes of the EPC and 12 bytes of the TID and 16 bytes
of the user data area starting at address 64 are to be
included:
Calculation format: "%E[0.12]%T[0.12]%U[64.16]"
For details on signature generation and verification, see
Data security on page 11.
Adjustable values:
Length
[byte]
007:
Meaning
0...99
Web and
OPC UA:
Suffix for
0...1024
ReadMul-
tipleTag-
DataFor-
matted
100B
hex
–
SetTagSignatureFormat/GetTagSigna-
tureFormat method
–
Permissi- Factory setting
ble
values
String "%E[0.12]%T[0.8]"
12 byte EPC +
8 byte TID
english
Meaning
Calcula-
tion
format for
signature
generation
