Processor unit
7
Startup and operation (continued)
Access password
Parameter-ID: 1002
hex
UHF-Manager: Action area > R
OPC UA: Is applied with the respective OPC UA
methods for writing and reading
Webserver: Menu: RFID > Action area: t
teRS
If a password-protected data carrier is to be accessed, the
data carrier can be unlocked for further interaction using
the Access password parameter.
The password must be transferred in LSB first format.
If no data carriers with different passwords are in use, it is
sufficient to send the parameter once to the processor
unit.
The password remains stored in the processor unit until
the current session is ended or the processor unit is
restarted.
Adjustable values: 4-byte password (Standard
Length Permissible
[bits] values
(hex)
32 00000000...
FFFFFFFF
54 english
/ tab
ead wRite
ag paRame
00 00 00 00 )
hex
Factory Meaning
setting
(hex)
00000000 Access
password
Memory bank
Parameter-ID: 0x1004
UHF-Manager: Action area > R
OPC UA: Is applied with the respective OPC UA
methods for writing and reading
- Webserver: Menu: RFID > Action area: t
teRS
The parameter Memory bank can be used to control the
memory area of the data carrier on which write/read
operations are executed.
Depending on the data carrier used, the memory areas of
RFU (Reserved), EPC, TID and USER are available.
If the memory area is changed, the setting is retained until
it is changed again or the session is terminated.
Length Permissi-
[bits] ble values
8 0, 1, 2 or 3
Further information on the different storage
areas of the data carriers can be found in the
EPCglobal
UHF RFID systems (www.epcglobal.de).
hex
/ tab
ead wRite
ag paRame
Factory Meaning
setting
3 (USER) Memory bank of
data carrier
0: RFU
1: EPC
2: TID
3: USER
Class-1 Generation-2 standard for
TM
-
