Processor unit
7
Startup and operation (continued)
WaitTime
Parameter-ID: 100E
hex
UHF-Manager: –
OPC UA: SetASyncFilter/GetASyncFilter methods
Webserver: –
The WaitTime parameter specifies the time interval after
which a data carrier reported as Goes can be re-detected.
This parameter overwrites the WaitTime (default) parameter
and is valid until the current TCP session is terminated or
the processor unit is restarted.
The 16-bit value is coded in 2 bytes in the order
Low – High.
Adjustable values:
Length Permissi-
[bits] ble values
16 0...1000
64 english
Factory Meaning
setting
0 Time in seconds
during which a
data carrier is
ignored
Data filter
Data filters can be used if only a subset from a data carrier
population is to be detected. For this purpose, various
criteria can be defined that describe the desired subset.
For example, only data carriers whose EPC corresponds
to a certain length or whose TID contains a special data
sequence can be detected.
EPCLengthMin (default)
Parameter-ID: 002B
hex
UHF-Manager: –
OPC UA: SetFilter/GetFilter methods
Webserver: –
The EPCLengthMin and EPCLengthMax parameters can
be used to define a filter that excludes data carriers during
detection if their EPC length is not within the specified filter
range.
The parameter EPCLengthMin (default) defines the
minimum EPC length in bytes, which is set after switching
on or after a restart of the processor unit.
Adjustable values:
Length Permissi- Factory
[bits] ble values setting
8 0...62 0 (0 byte)
EPCLengthMin
Parameter-ID: 100F
hex
UHF-Manager: –
OPC UA: SetFilter/GetFilter methods
Webserver: –
The EPCLengthMin and EPCLengthMax parameters can
be used to define a filter that excludes data carriers during
detection if their EPC length is not within the specified filter
range.
The EPCLengthMin parameter sets the minimum EPC
length in bytes and overwrites the EPCLengthMin (default)
parameter until the current TCP session is terminated or
the processor unit is restarted.
Adjustable values:
Length Permissi- Factory
[bits] ble values setting
8 0...62 0 (0 byte)
Meaning
EPC minimum
length for filter
(default)
Meaning
EPC minimum
length for filter
(temporary)
