Processor unit
8
007 protocol (continued)
Command identifier 'g': IO-Link master
configuration, write
Write the IO-Link master configuration.
Byte Length Command
element
00 1 Command
identifier (ASCII)
01 1 Cycle Time Base
(ASCII)
02...03 2 Cycle Time
(ASCII)
04 1 IO-Link mode
Pin4 (ASCII)
05 1 IO-Link mode
Pin2 (ASCII)
06 1 Safe State
(ASCII)
07 1 Validation (ASCII)
08 1 Parameter server
(ASCII)
09 1 Upload parame-
ters (ASCII)
10 1 Parameter
download (ASCII)
11...14 4 Vendor ID (ASCII
hex)
15...20 6 Device ID (ASCII
hex)
21...22 2 Output Length
(ASCII)
23...24 2 Input Length
(ASCII)
25...40 16 Serial Number
(ASCII)
41 1 BCC
www.balluff.com
Status message:
Byte
Value range
00
'g'
01
'0': 0.1 ms
If the status message is positive, the parameter data can
'1': 0.4 ms
be accepted with <STX>.
'2': 1.6 ms
'00'...'63' Byte
'0': Input NO
00
'1': Input NC
'2': Reserved
'3': Output
Status message:
'4': IO-Link data
Byte
'5': Input
NO – SIO
'6': Input
00
NC – SIO
'0': Input NO
01
'1': Input NC
'2': Reserved
'3': Output
'0'...'2'
'0': No validation
'1': Compatible
'2': Identical
'0': Disabled
'1': Delete
'2': Enabled
'0': Disabled
'1': Enabled
'0': Disabled
'1': Enabled
"0000"..."FFFF"
"000000"...
"FFFFFF"
"00"..."32"
"00"..."32"
ASCII-String
00 ...FF
hex hex
Length Command
element
1 Status
1 Status code
Length Command
element
1 Control com-
mand
Length Command
element
1 Status
1 Status code
english
Value range
<ACK> or
<NAK>
See Status codes
on page 94
Value range
<STX>
Value range
<ACK> or
<NAK>
See table
Status codes
on page 94
