Processor unit
7
Startup and operation (continued)
NTP server
Parameter-ID: 0021
hex
UHF-Manager: Menu: Device settings > Parameters...
> Device parameters
OPC UA: –
Webserver: Menu: Configuration > Network
If the network has access to an NTP server (Network Time
Protocol or time server), time synchronization can be
performed via the network using this server. The parameter
NTP server defines how this time server is to be reached.
A string with a maximum of 63 characters (bytes) is
transferred as the parameter value, which can contain a
URL or an IP address, e.g. "time.google.com" or
"192.168.10.1".
Adjustable values:
Length Permissible Factory
[byte] values setting
0...63 URL or valid ""
IPv4 address
as string
Time
Parameter-ID: 0022
hex
UHF-Manager: Menu: Device settings > Parameters...
> Device parameters
OPC UA: –
Webserver: Menu: Configuration > Device
The Time parameter can be used to set the date and time
manually if no NTP server is available on the network.
Adjustable values:
Length Permissible Factory
[byte] values setting
14 Date and Continuously
time in the updated
format
"YYYYMMD-
Dhhmmss"
www.balluff.com
FormattedTagData (default)
In the chapter Parameters for experts on page 50, the
FormattedTagData function is described with the relevant
parameters. With a login of the e
parameters can only be changed temporarily or in relation
to a TCP session.
The a
default values that are used after the processor unit is
switched on or restarted.
In the 007 protocol up to 99 characters can be defined.
With OPC UA or with the web interface longer strings (up
to 1024 characters) can also be defined, which are also
valid in the 007 protocol.
Format definition for ReadTagDataFormatted,
ReadMultipleTagDataFormatted and
WriteFormattedTagData (default)
Parameter-ID:
Meaning
UHF-Manager:
URL or address
OPC UA:
of the NTP
server
Webserver:
Defines the default data format for the FormattedTagData
function to be used after switching on or restarting the
processor unit.
Adjustable values:
Length
[byte]
007:
0...99
Meaning
Web and
OPC UA:
Date and time
0...1024
in the format
"YYYYMMD-
Dhhmmss"
xpeRt
security level can also be used to define the
dmin
0025
hex
Menu: Device settings > Parameters...
> Read > Write
SetTagDataFormatted/GetTagDataFor-
matted method
Configuration > RFID > Formatted tag
data
Per- Factory setting
missi-
ble
values
Format- "%Ex[0.12]#0d#0a"
String EPC string with
CR LF
english
security level, these
Meaning
Format string
for ReadTag-
DataFormat-
ted, Read-
MultipleTag-
DataFormat-
ted and
WriteFormat-
tedTagData
79
