TECHNICAL DATA

10.2. SPECIAL VERSIONS

70-NET can be customised to provide galvanic isolation and voltage adaption for specific
load requirements. The following versions are available upon order:
T-version
70-NET-T includes an isolation transformer at the input. This transformer is installed in
place of the batteries and provides complete electrical isolation between the load and the
input mains utility. Technical data differs according to the following table:
DESCRIPTION
Electrical Data
Voltage
INPUT
Current (single phase)
Frequency
Power rating
Voltage
OUTPUT
Current @400Vrms
Frequency
Waveform
Max. dissipation
(@ nominal load; battery recharging)
Mechanical Data
Depth
Width
Height
Weight (without batteries)
Max. noise level (@1m)
Page 56 User Handbook - 10H52163PAMC rev.9 - 06/2008
CHLORIDE 70-NET 10 - 40KVA
Unit
kVA 10 15
Vrms 400, 3ph (+N), +15%,
(-30% with derating)
Arms 17 22
Hz 50/60 (auto selection)
kVA 10 15
kW 8 12
Vrms 380, 400, 415, 3ph (+N)
Arms 14 22
Hz 50/60 (auto selection)
-
kW 1.2 1.5
mm
mm 500
mm 1400
kg 280
dB <55
Rating
20 30 40
29 44 58
20 30 40
16 24 32
29 43 58
Sinusoidal
1.8 2.6 3.5
800
550
1600
380 460
<58
