NORMAL AND SAFE OPERATION
Press the Inverter OFF
• Silencing Buzzer
To silence the Buzzer press the Reset button momentarily
• Fault Reset
In order to restore normal operation of the UPS following a fault condition, after having cor-
rected the situation causing the fault, press the Reset button for at least one second.
.
"Select Left"
Button"
"Menu Down"
Button"
"Inverter OFF"
Button"
"OK" LED (green) - Il-
luminated when Load
is on Inverter - Flash-
ing when when Load
is on Battery
The TEST / RESET button serves as a function control for the LEDs of the control panel
and resets the UPS after the fault has been corrected. All LEDs on the control panel illumi-
nate for approx. 1.5 s after pressing the button in normal operation (no warning or fault in-
dicators present), followed by the last five warning indicators appearing one after the other
in the two-digit display. If a fault occurs, pressing the button mutes the audible signal and,
once the fault has been corrected, pressing the button brings the UPS into operation again.
The UPS can be manually switched between bypass and on-line operation using the keys
"Inverter ON" (I) and "Inverter OFF" (O). A PC can be connected to the service plug (SERV-
Page 34
button for five seconds
Figure 23 - Control Panel
User Handbook - 10H52163PAMC rev.9 - 06/2008
CHLORIDE 70-NET 10 - 40KVA
Display
"Menu Up"
Button"
"Select Right"
Button"
"Inverter ON"
Button"
"Fault" LED (red) -
Flashes if FAULT
condition
sage is present
"Reset" Button
"Warning" LED (yellow) -
Flashes if WARNING con-
dition message is present
mes-
