CHLORIDE 70-NET 10 - 40KVA

9. OPTIONS

9.1. EXTERNAL BATTERIES

Additional, external battery solutions are available to increase the autonomy of operation of
the UPS. These include the following components:
• Cubicle
• Disconnecting device
• Fuses
• Safety screen
• Power terminal block
in addition to the approriate battery solution, if requested. Three cubicle sizes are available:
Type A
Type A1
Type A2

9.2. SHUTDOWN AND MONITORING SOFTWARE

MopUPS
The primary function of MopUPS for Windows is to shut down the operating system of an
unattended computer, safely, in the event of a power failure. All files are closed and direc-
tory pointers are written to disk while the system is supplied from UPS battery power.
MopUPS for Windows provides this function and offers other features, useful to network ad-
ministrators, including:
• Automated responses to a variety of events – E-mail, messaging, paging, running
script files, etc.
• Logging of various events and UPS status information to files
• Real time viewing of site power and UPS status information
• Administrative shutdown for scheduling planned system shutdowns
• Control of UPS performance features - set restart to manual, silence alarms, adjust
trip points
• Remote access and monitoring of UPS connected to remote servers on the network
using Named Pipes or TCP/IP

9.3. SHUTDOWN SOFTWARE FOR COMPUTER INTERFACE PORT

Network adaptor ManageUPS
ManageUPS (formerly known as the SNMP adapter) allowing 70-NET UPS to be monitored
and controlled over a network using TCP/IP protocol. The adapter allows:
• UPS monitoring from an NMS station using SNMP
• UPS monitoring from a PC using a Web Browser
• Notification of events via E-mail

9.4. AS400 MULTIPLEX

For connection between the UPS and an AS400 type computer, or similar, a 50 m cable,
complete with the appropriate connectors, is available.
User Handbook - 10H52163PAMC rev.9 - 06/2008
Table 8: . Empty battery cubicles
Width Depth
mm mm
820 830
500 800
500 800
Height Weight
mm kg
1780 220
1600 100
1400 90
OPTIONS
ENG
Page 51
