NORMAL AND SAFE OPERATION

6.10. WARNING AND FAULT INDICATIONS

The UPS recognises and draws attention to a number of events occurring during operation. These
events are divided into Warning and Fault indications. Whether the message is a warning or fault
can be determined from the number which appears in the Warning/Fault Diagnosis page of the dis-
play, and the buzzer signals.
Buzzer
The buzzer has two different patterns, which indicate the tyre of warning active.
• Pattern 1: long intervals - This event is less serious. It is not essential that the
cause be rectified immediately, unless otherwise specified in table "Warning indica-
tors".
• Pattern 2: short intervals - This is a serious event. The cause should be rectified
straight away to avoid a fault condition.
The buzzer is silenced automatically as soon as the cause of the event is rectified. It can
also be silenced manually by pressing the button TEST/RESET.

Warning indicators

If a warning indication appears, the UPS continues to operate. The yellow LED ALARM il-
luminates on the control panel. A number between 1 and 31 appears in the display indicat-
ing the type of warning.
Displayed Warnings
The various possible warning indications are listed in the following table.
Warning
indicator-
Buzzer
pattern
1 - 2 temperature too high in device
2 - 1 power failure (bypass power failure) *
3 - 1
4 - 2
5 - 2 low intermediate circuit voltage
6 - 1
7 - 2
8 - 1
9 - 1
10 - 2 battery rest time exceeded **
11 - 2
12 - 1 operating state: commissioning,
initial charging, converter
13 - 1 battery switch not engaged
14 - 1
15 - 1 battery charger comms. failure
19 - 1 battery temperat. out of tolerance
23 - 1 battery charger failure (from charger)
24 - 1 battery charger failure (from CU)
Page 40
Table 6: Warning indicators
Cause
power failure (converter)
load too high
load too high
wrong phase sequence
service bypass is on
Battery operation
discharge battery **
fan lifetime exceeded
User Handbook - 10H52163PAMC rev.9 - 06/2008
CHLORIDE 70-NET 10 - 40KVA
Corrective steps
lower temperature (e.g. with ventilation); if nec-
essary, reduce load; ensure ventilation outlets
are unobstructed.
reduce load
reduce load
check phase sequence
switch off load directly
reduce load
exit operating state after commissioning,
initial charging
engage battery switch
replace fan - call customer service
call customer service
call customer service
call customer service
