en
4.7 Type key
4.8 Scope of delivery
4.9 Accessories
5 Transportation and storage
5.1 Delivery
5.2 Transport
138
Transportation and storage
Non-immersed [OTe]
* Operating mode S3 50 % is permitted if the necessary motor cooling is guaranteed
before the motor is switched on again! To ensure the required cooling, the motor must
be completely immersed for at least 1 min.!
Statement of date of manufacture
The date of manufacture is stated in accordance with ISO 8601: JJJJWww
▪ JJJJ = year
▪ W = abbreviation for week
▪ ww = calendar week
Example: Wilo-Rexa CUT GE03.25/P-T15-2-540X/P
Series
CUT
Grinder pump with external macerator
GE
Nominal diameter of the pressure connection: DN 32
03
Max. delivery head in m
25
Surface-cooled motor with grey cast iron housing
P
Mains connection version: M = 1~, T = 3~
T
/10 = rated power P
15
Number of poles
2
Mains connection frequency: 5 = 50 Hz, 6 = 60 Hz
5
Code for rated voltage
40
Ex rating:
X Without = without Ex rating
X = with Ex rating
Additional electrical equipment:
P Without = with bare cable end
P = with plug
▪ Pump
▪ Cable with plug or bare cable end
▪ Single-phase current version with capacitor switchgear
▪ Installation and operating instructions
▪ Cable lengths in fixed length increments of 10 m (33 ft) up to max. 30 m (99 ft) in
single-phase current version or max. 50 m (164 ft) in three-phase current version
▪ Suspension unit
▪ Pump support foot
▪ External pencil electrode for sealing chamber control
▪ Level control devices
▪ Fixation accessories and chains
▪ Switchgear, relays and plugs
After receiving the shipment, this must be checked immediately for defects (damage,
completeness). Defects must be noted on the freight documentation! Furthermore, de-
fects must be notified to the transport company or the manufacturer immediately on
the day of receipt of shipment. Subsequently notified defects can no longer be asser-
ted.
WARNING
Standing under suspended loads!
Never allow anyone to stand under suspended loads! Danger of (serious) injuries
caused by falling parts. Loads may not be carried over work places where people are
present!
S2-30, S3 25%*
in kW
2
